perspective drawing board

Very easy to make. Any line drawn with the rulers conforms to 2-point perspective.



This is a useful drawing board that can be made from cardboard & strips of scrap wood with a small amount of PVA



This shows the reinforcement at the back




pantograph

Make this from strips of card. It copies images: the worse you make it, the more it stretches and distorts the original. Follow the original image with the pointer, the pen produces the copy. If for one reason or another you feel you are unable to saw a felt-tip in half then remove the ink-tube and tip from the plastic body. Or just use the pen as is.





Here we see one copying one side of the rabbit's face: original is green, copy is blue.



This is an attachment for a pantograph



it constrains one side to move in a circle whilst at the same time winding in a bit of cotton.
It is rather a laborious design, this is a much simpler way of doing the same thing



The cotton pulls the paper round when the handle is turned. The card holding the paper has a drawing pin through it in the top-right-hand corner, the drawing pin is taped to the table
The winder also bears on a drawing pin taped to the table



The simplified pantograph consists just of a loop of garden wire taped to the table at one end and holding a pen at an intermediate point



This is a detail of the attachment of the cotton to the card & the winder


Movie


This is a better design



Rotate the right-hand wheel with your right hand, the paper with your left, but only when the movement won't show on the pattern i.e. when the line is tangential



This is a detail of the end of one of the pivot arms. You can change the pattern by moving the blob of blue-tack along one of the pivot arms. The central pin that holds the two pivot arms together is stuck to the table with blue-tack.



This is a detail of the right-hand wheel. You could trace the wire pointer round a stencil instead or just use it as a normal pantograph. The centre of the wheel is stuck to the table, it is dog-eared to make it easier to turn.
If you unstick the central pivot pin from the table and stop rotating the paper but turn the right-hand wheel the whole thing rotates slowly about the right-hand pivot. I'm not sure why.




pantograph controlled by cardboard disc

coke-can planimeter


computer controlled etch-a-sketch



wobbling pen

Use these to make banknotes. Stimulates an interest in large numbers.



spinning pen

Similar thing but a bit more complex. Does much bigger circles.



The bent wire constrains the pen to follow the rotation of the wheel



The end of the bent wire can be stuck into the wheel at a number of points giving different size circles



The bend of the wire is quite critical. Less critical if you use more than one battery but then less tactile.



Just one piece of bent wire. One end in center of wheel; about one inch then a bend to stick the motor to; a long loop then another bend to stick the pen to; about two inches then a small bend at the end to locate in one of the eccentric holes in the wheel.
link to movie



This does a similar thing but with several pens at once



It is made of a plastic cogwheel with a wire & cardboard frame to hold the pens, this one will hold up to four at different diameters



The cogwheel is placed in a carboard holder where it is driven round by a worm gear, you slide the holder around to draw the paterns



the worm gear in the picture must turn clockwise or it lifts the cogwheel out of the holder. It is quite difficult to do a centerless wheel, this is the only way I could find that works. Any central bearing would obstruct the pens.


not quite sure how this works



ink centrifuge

These patterns can be made with a felt tip if you're careful not to make a mess.



Stick three sheets of paper together to form a cylinder, then spin a felt tip round an an axis sideways through its middle. This one is being done with an electric motor



If you angle the plane of rotation slightly you end up with the wavy lines. You can make a thing for doing it by pulling a string, you don't have to spin the pen very fast. Link to movie





You can even do it by spinning some kind of axle between the palms of your hands; here the axle is a thinner felt-tip



Although you really need something thinner like a kebab stick or you can't spin it fast enough.



Press that button at your peril......





motorising a 4-colour pencil

This is a motorised 4-colour pencil; make a plastic tube by cutting up a felt-tip lid or out of cardboard, it must be quite a good loose fit. The pencil will require frequent sharpening so it must be easy to dismantle.






spirographs

Spirographs can be made from cheap plastic gearwheels just by making a radial cut with a pair of scissors to 'add' a gear tooth





YouTube movie of very ambitious one



This is my version of a more complex spirograph. I had the cogwheels left over from assembling gearboxes, they always include more cogwheels than you need in case you want to make up a very low gear ratio



It can do a wide variety of patterns



Here it is with some of the linkages removed, in this configuration it does symetrical patterns



The key to the technique is shimming sewing pins with paper, the cogwheels can then be precisely mounted on a bit of cardboard



The paper is rolled between finger & thumb



As with the much simpler spirograph described earlier an extra tooth is added to the final cogwheel which carries the paper



this shows it in situ



if you are uncomfortable with this method of adding a tooth to a cogwheel , have a look at some cogwheels made with a 3D printer or even stranger a method for making them out of bent wire. Strange it may be, but it seems to work. You can also make them out of styrofoam using a hot wire cutter or with a computer controlled router
more weird gearwheels
3D weird gearwheels
Some backlash is necessary between the cogwheels or they stick & jerk the pattern. These are the central eccenric bearings



This shows one of the linkages that transfer the eccentric rotation to the pen arm



youtube



It's a bit like trying to find the lost chord





drawing a spiral

This can be done with a drawing pin, a short length of cotton and tiny amount of blue tack



You need a cardboard drawing board to stick the drawing pin through and you have to make a cardboard washer, it works surprisingly well. Works well with a biro because of the profile of the tip.


camera obscura

Very simple, works quite well. Can be adapted as water-drop microscope.



The sheet of paper must be rigidly mounted on the bottom of the box. The subject must be very well lit.
Interesting camera obscura link
